SUMORE SP-D35 DRILLING MACHINE 35MM /380V 3-PHASE
SUMORE / SP-D35
Industrial vertical geared drilling machine SP‐D35 with 12‐speed gearbox (70–2600 rpm), 35 mm drilling capacity, MT4 spindle taper, and spindle feed rates of 0.1 / 0.2 / 0.3 mm/rev. It has 150 mm spindle travel, a 424×424 mm table with ±45° tilt and 540 mm vertical travel, plus a 420×380 mm base and 140 mm column diameter.
Industrial vertical geared drilling machine SP‐D35 with 12‐speed gearbox (70–2600 rpm), 35 mm drilling capacity, MT4 spindle taper, and spindle feed rates of 0.1 / 0.2 / 0.3 mm/rev. It has 150 mm spindle travel, a 424×424 mm table with ±45° tilt and 540 mm vertical travel, plus a 420×380 mm base and 140 mm column diameter.
Technical Specifications
| Specification | Details |
|---|---|
| Model | SP-D35 |
| Drilling capacity | 35mm |
| Spindle travel | 150mm |
| Spindle taper | MT4 |
| Number of speeds | 12 |
| Speed range | 70-2600 rpm |
| Feed rates | 0.01/0.2/0.3 mm/rev |
| Table travel | 540 mm |
| Table tilt | ±45° |
| Table size | 424x424mm |
| Base size | 420x380mm |
| Column diameter | 140mm |
| T‐slots (number / size) | 2 / 14 & 16mm |
| Main motor | 1500/2200 W |
| Coolant motor | 90 W |
| Gross weight | 730 kg |
| Net weight | 670 kg |
| Packing size | 700×1150×2150 mm |
