DRILLING MACHINE SP-D3113S 50MM HEAVY DUTY GEARBOX
SUMORI ESPANZA / SP-D3113S
This vertical drilling machine has a modern, compact design with a wide spindle speed range and simple, user‐friendly operation. Its worktable rotates 180° and tilts +45°/−45°, with both motor‐driven and manual lifting for flexible setup. A coolant system, tapping mechanism, and IEC‐standard electrical system with short‐circuit and overload protection make it reliable for small‐batch and mass‐production drilling, boring, reaming, tapping, and spot‐facing work.
This vertical drilling machine has a modern, compact design with a wide spindle speed range and simple, user‐friendly operation. Its worktable rotates 180° and tilts +45°/−45°, with both motor‐driven and manual lifting for flexible setup. A coolant system, tapping mechanism, and IEC‐standard electrical system with short‐circuit and overload protection make it reliable for small‐batch and mass‐production drilling, boring, reaming, tapping, and spot‐facing work.
Technical Specifications
| Specification | Details |
|---|---|
| Model | SP-D3113S |
| Max drilling capacity | 50mm |
| Diameter of column | 170mm |
| Spindle travel | 180mm |
| Distance spindle axis to column generating line | 360mm |
| Max distance spindle nose to table | 600mm |
| Max distance spindle nose to table | 1205mm |
| Spindle taper | MT4 |
| Spindle speeds range | 42-1865r/min |
| Spindle speeds series | 12 |
| Spindle feeds 4 | 0.07,0.15,0.26,0.40r/min |
| Dimension of worktable surface | 500×370mm |
| Table travel | 525mm |
| Dimension of base table | 460×450mm |
| Overall height | 2300mm |
| Main motor | 2.2/2.8kw |
| Coolant motor | 0.024kw |
| Gross weight / Net weight | 860/800kg |
