TAB-D40 MILL DRILL 40MM + COOLANT + WORK LIGHT /380V 3PH
AL-TABSH / TAB-D40
The TAB D-40 Drilling Machine features a newly designed, attractive appearance, compact construction, and a broad speed change range for easy operation. It is equipped with a unique worktable that allows both motor-driven and manual lifting. The machine also includes a coolant system, shortcut protection, and overload protection for enhanced functionality and safety.
The TAB D-40 Drilling Machine features a newly designed, attractive appearance, compact construction, and a broad speed change range for easy operation. It is equipped with a unique worktable that allows both motor-driven and manual lifting. The machine also includes a coolant system, shortcut protection, and overload protection for enhanced functionality and safety.
Technical Specifications
| Specification | Details |
|---|---|
| Model | TAB-D40 |
| Drilling capacity | 40 mm |
| Spindle taper | M.T.4 |
| Max spindle travel | 130 mm |
| Distance spindle center to column | 283 mm |
| Max distance spindle nose to table | 725 mm |
| Max distance spindle nose to base | 1125 mm |
| Max travel of worktable support | 600 mm |
| Max travel of spindle box | 250 mm |
| Worktable size | 380 mm |
| Spindle speeds (6 steps, 60 Hz) | 95, 175, 450, 850, 1500 r/min |
| Feed steps of spindle (6) | 0.12, 0.15, 0.18, 0.30 mm/rev |
| Base dimensions | 417 × 416 mm |
| Motor power | 1.1 kW |
| Motor voltage | 220/380 V, three phase |
| Motor speed | 1400 r/min |
| Overall dimensions | 1850 × 750 × 1000 mm |
| Gross weight | 430 kg |
