LATHE SP2112-I SUMORE 330 X 1000MM COOLANT LIGHT 380V
SUMORE / SP2112-I
Light‐duty metal lathe model SP2112‐I from Chinese manufacturer SUMORE is suitable for precise turning work, offering high rigidity and stability with a working capacity of 330 mm swing diameter × 1000 mm between centers.
Light‐duty metal lathe model SP2112‐I from Chinese manufacturer SUMORE is suitable for precise turning work, offering high rigidity and stability with a working capacity of 330 mm swing diameter × 1000 mm between centers.
Technical Specifications
| Specification | Details |
|---|---|
| Model | SP2112-I |
| Swing over bed | 330 mm |
| Swing over cross slide | 198 mm |
| Swing in gap diameter | 476 mm |
| Swing in length of gap | 210 mm |
| Center height | 166 mm |
| Distance between centers | 1000 mm |
| Bed width | 187 mm |
| Bed length | 1655 mm |
| Spindle bore | 38 mm |
| Spindle nose | D1‐4 |
| Taper in sleeve | Morse No.3 |
| Number of speeds | 8 |
| Speed range | 70–2000 rpm |
| Cross slide travel | 160 mm |
| Compound rest travel | 68 mm |
| Lead screw thread | 8 TPI |
| Feed rod diameter | 19 mm |
| Max cutting tool section | 16×16 mm |
| Imperial thread pitches | 36 types (8–112 TPI) |
| Metric thread pitches | 28 types (0.2–5 mm) |
| Longitudinal feeds (imperial) | 36 types (0.0019–0.0273 inch/rev) |
| Longitudinal feeds (metric) | 36 types (0.050–0.696 mm/rev) |
| Cross feeds (imperial) | 36 types (0.0006–0.0094 inch/rev) |
| Cross feeds (metric) | 36 types (0.013–0.188 mm/rev) |
| Quill diameter | 32 mm |
| Quill travel | 100 mm |
| Quill taper | Morse No.3 |
| Main motor | 1.5 kW, 3‐phase |
