COMBINED LATHE MACHINE 3 IN 1 BL270 250 X 700 WITH TABLE

COMBINED LATHE MACHINE 3 IN 1 BL270 250 X 700 WITH TABLE

PAN SINO / BL270

The BL270 3-in-1 mini lathe, drilling, and milling machine combines multiple machining operations in one compact unit. It helps save workspace, reduce handling time, and improve machining accuracy. Designed for small workshops and modern machining needs, it is ideal for cutting, drilling, and milling small parts efficiently.

Export Catalogue

SKU: SALLA-2069055640 Category:

The BL270 3-in-1 mini lathe, drilling, and milling machine combines multiple machining operations in one compact unit. It helps save workspace, reduce handling time, and improve machining accuracy. Designed for small workshops and modern machining needs, it is ideal for cutting, drilling, and milling small parts efficiently.

Technical Specifications

SpecificationDetails
ModelBL270
Distance between centers700mm
Swing over bed250mm
Swing over cross slide130mm
Taper of spindle boreMT4
Spindle bore27mm
Number of spindle speedsVariable
Range of spindle speeds115-1620 rpm 2
Range of metric threads0/0.2-3.5 mm,
Range of inch threads20/8-56 T.P.I
Motor550 w
Top slide travel50mm
Cross slide travel120mm
Tailstock quill travel50mm
Tailstock quill TaperMT2
Packing size1580x680x880mm
Net weight225kg
Mill & Max.drilling dia16mm
Max.end milling capacity20mm
Max.face milling capacity50mm
Vertical travel220mm
Taper of spindle boreMT2
Spindle travel50mm
Spindle speed50-2250 rpm
Motor for (drill/mill)600w
