SLOTTING MACHINE SUMORE BRAND SP5032
SUMORE / SP5032
The SP5032 Slotting Machine is designed for accurate internal and external slotting operations. It features strong cutting force, adjustable ram movement, and a large worktable capacity for industrial machining applications.
The SP5032 Slotting Machine is designed for accurate internal and external slotting operations. It features strong cutting force, adjustable ram movement, and a large worktable capacity for industrial machining applications.
Technical Specifications
| Specification | Details |
|---|---|
| Model | SP5032 |
| Max. Slotting Length | 320 mm |
| Max. Workpiece Size | 600 × 320 mm |
| Max. Workpiece Weight | 500 kg |
| Max. Cutting Force | 7500 N |
| Strokes per Minute | 20, 32, 50, 80 rpm |
| Ram Adjustment | 315 mm |
| Table Diameter | 630 mm |
| Table Travel | 480 / 620 mm, Cross: 480 / 560 mm |
| Main Motor Power | 4 kW |
| Overall Size | 2180 × 1550 × 2285 mm |
| Weight | 3500 kg |
