MILLING MACHINE TAB-UM50 WITH DRO 380V

MILLING MACHINE TAB-UM50 WITH DRO 380V

AL-TABSH / TAB-UM50

TAB-UM50 is a multifunctional drilling and milling machine. The vertical milling, and the horizontal milling. Boring Grinding, and tapping

Export Catalogue

SKU: SALLA-684078472 Category:

TAB-UM50 is a multifunctional drilling and milling machine. The vertical milling, and the horizontal milling. Boring Grinding, and tapping

Technical Specifications

SpecificationDetails
ModelTAB-UM50
Max. drilling diameter50 mm
Max. horizontal milling length100 mm
Max. vertical milling diameter32 mm
Distance from vertical spindle center+/- 90 °
to surface of column Max. boring diameter120 mm
Spindle taperISO 40 or MT4
Spindle travel (end milling)130mm
Distance between spindle and table80-480 mm
Table size1000×240 mm
Table travel785×300 mm
Spindle feed0.012; 0.08; 0.25 mm / rev
Motor1.5 kw
Overall dimensions1120x1060x2035 mm
Net weight920kg
