MILLING MACHINE SPUM2246 WITH DRO TABLE SIZE 1370 X 320MM 380V

MILLING MACHINE SPUM2246 WITH DRO TABLE SIZE 1370 X 320MM 380V

SUMORI ESPANZA / SPUM2246

SPUM2246 professional heavy duty Milling Machine is one of our most economical and durable heavy duty milling machine

Export Catalogue

SKU: SALLA-342552916 Category:

SPUM2246 professional heavy duty Milling Machine is one of our most economical and durable heavy duty milling machine

Technical Specifications

SpecificationDetails
ModelSPUM2246
Spindle taperISO40
Distance from spindle to table200~650mm
Spindle speedsspindle)
Table size1370x320mm
Table travel(horizontal/cross)1000/380mm
Feeding range of longitudinal cross travel22~430mm/min
Feed motor0.55kw
Max. weight of workpiece400kg
T-slot no. /width/distance3/14mm/70mm
Distance from vertical spindle center200-760mm
to surface of column Distance from horizontal spindle20mm~470mm
center to table surface Elevating travel of table450mm
Main motor3 kw
Cooling motor0.09kw
Overall dimension2020x1710x1994mm
Elevating motor0.75kw
Net weight2000kg
