CAYKEN KRO-550 MAGNETIC DRILL MACHINE 220V SINGLE PHASE
CAYKEN / KRO-550
CayKen KCY-36/2WDO Magnetic Drill – multi‐function industrial drilling up to 36 mm / M18. KCY‐36/2WDO magnetic drill supports core drilling up to 36 mm, twist drilling up to 18 mm, and tapping up to M18, powered by a 1550 W 220 V single‐phase motor with two speed ranges: 100–360 and 360–660 rpm, and cutting depth around 30 mm with stroke up to about 220 mm. Delivers magnetic holding force around 14200 N, includes soft start, electronic overload protection, oil‐immersed gearbox, and comes in a compact 58×17×37 cm plastic case with net weight about 13 kg, making it suitable for professional fabrication, installation, and on‐site steel work.
CayKen KCY-36/2WDO Magnetic Drill – multi‐function industrial drilling up to 36 mm / M18. KCY‐36/2WDO magnetic drill supports core drilling up to 36 mm, twist drilling up to 18 mm, and tapping up to M18, powered by a 1550 W 220 V single‐phase motor with two speed ranges: 100–360 and 360–660 rpm, and cutting depth around 30 mm with stroke up to about 220 mm. Delivers magnetic holding force around 14200 N, includes soft start, electronic overload protection, oil‐immersed gearbox, and comes in a compact 58×17×37 cm plastic case with net weight about 13 kg, making it suitable for professional fabrication, installation, and on‐site steel work.
Technical Specifications
| Specification | Details |
|---|---|
| Model | KRO-550 |
| Core drill capacity | 36 mm |
| Twist drill capacity | 18 mm |
| Tapping capacity | M18 |
| Voltage/Frequency | 220V/60HZ single phase |
| Power | 1550 W |
| No-load speed(1) | 100-360 rpm |
| No-load speed(2) | 360-660 rpm |
| Max magnetic force | 14200 N |
| Cutting depth | 30 mm |
| Cable length | 2.5M |
| Stroke | 220 mm |
| Net/Gross weight | 13/18.5 kg |
| Machine size | 58 × 17 × 37 cm |
| Packing | Plastic box |
