SUMORE MILLING MACHINE X6325 WITH DRO TABLE SIZE 254 X 1270MM 380V

SUMORE MILLING MACHINE X6325 WITH DRO TABLE SIZE 254 X 1270MM 380V

SUMORE / X6325

X6325 milling machine is one of our most economic and durable milling machine ( with or without DRO )

Export Catalogue

SKU: SALLA-2048340682 Category:

X6325 milling machine is one of our most economic and durable milling machine ( with or without DRO )

Technical Specifications

SpecificationDetails
ModelX6325
Table size254x1270mm
Longitudinal travel850mm
Cross travel400mm
Vertical travel420mm
T-slot no. and size3×16
Ram travel470mm
Distance from spindle nose to table surface0~420mm
Spindle hole taperR8/ISO30/ISO40
Spindle travel127mm
Main motor2.25Kw or 3.75Kw
Diameter of quill95mm
Distance from spindle to table90~370mm
Distance from horizontal spindle to table0~280mm
Distance from spindle to column200~700mm
Spindle speeds(16 step)80~5440 rpm(V)40~1300rpm(H)
Feeding of quill(3 step)0.04 0.08 015
Swivel90°
Head tilting45°
Dimension of package1616x1550x2080mm
Net weight1420kg
Gross weight1380kg
