DRILL PRESS SP5216A-I 16MM 550W SINGLE PHASE
SUMORE / SP5216A-I
SP5216A-I drill press is one of our most economic drill presses. it is small and delicate in design
SP5216A-I drill press is one of our most economic drill presses. it is small and delicate in design
Technical Specifications
| Specification | Details |
|---|---|
| Model | SP5216A-I |
| Drilling capacity | Ø16mm(5/8") |
| Motor power | 375/450/550W |
| Chuck capacity | 3-16mm |
| Spindle stroke | 60mm |
| Class of speed | 5 |
| Speed 60Hz | 620~2620/740~3140 R.P.M |
| Spindle taper | B16 |
| Auto-feeding step of worktable | 130mm |
| Max distance from spindle end to surface of table | 400mm |
| Max distance from spindle end to surface of base | 515mm |
| Swing | 260mm |
| Table size | 190X190mm |
| Base size | 340X210mm |
| Column diameter | Ø58mm |
| Height Net | 840mm |
| weight / Gross weight | 28/30kg |
