COMBINED MINI LATHE MACHINE 3 IN 1 BL125 125 X 180

COMBINED MINI LATHE MACHINE 3 IN 1 BL125 125 X 180

PAN SINO / BL125

The BL125 3-in-1 mini lathe, drilling, and milling machine combines multiple machining operations in one compact unit. It helps save workspace, reduce handling time, and improve machining accuracy, making it ideal for small workshops and efficient processing of small parts.

Export Catalogue

SKU: SALLA-1611856781 Category:

The BL125 3-in-1 mini lathe, drilling, and milling machine combines multiple machining operations in one compact unit. It helps save workspace, reduce handling time, and improve machining accuracy, making it ideal for small workshops and efficient processing of small parts.

Technical Specifications

SpecificationDetails
ModelBL125
Distance between centers180mm
Swing over bed125mm
Swing over cross slide60mm
Taper of spindle boreMT1
Spindle bore8mm
Number of spindle speedsVariable
Range of spindle speeds560-2500 rpm
Range of metric threads0.4-1.5 mm,
Range of inch threads16-48 T.P.I
Work Table size85×60mm
Top slide travel35mm
Cross slide travel80mm
Tailstock quill travel20mm
Tailstock quill TaperMT1
Motor250 w
Packing size520×300×410mm
Mill && Drill
Max.drilling dia6mm
Max.end milling capacity10mm
Max.face milling capacity25mm
Vertical travel125mm
Spindle travel40mm
Spindle speed500-2500rpm
