MINI LATHE TAB-ML180 X 350
AL-TABSH / TAB-ML180
The TAB ML-180 mini lathe gets the job efficiently, and affordably. This customized lathe machine from Altabsh has a modern, tested design, top installations, and safety regulations. Which can do most small works easily and fast. For usage in the light industry small workshops and central maintenance workshops for companies. With a 180mm swing, 350mm distance between centers, a wide range of speed feeds, and screw-cutting options, this lathe machine has an advantage over its competitors.
The TAB ML-180 mini lathe gets the job efficiently, and affordably. This customized lathe machine from Altabsh has a modern, tested design, top installations, and safety regulations. Which can do most small works easily and fast. For usage in the light industry small workshops and central maintenance workshops for companies. With a 180mm swing, 350mm distance between centers, a wide range of speed feeds, and screw-cutting options, this lathe machine has an advantage over its competitors.
Technical Specifications
| Specification | Details |
|---|---|
| Model | TAB-ML180 |
| Distance between centers | 350mm |
| Swing over bed | 180mm |
| Swing over cross slide | 100mm |
| Spindle taper | MT3 |
| Tailstock taper | MT2 |
| Chuck diameter | 100mm |
| Spindle bore | 21mm |
| Cross slide travel | 65mm |
| Tool slide travel | 35mm |
| Range of metric threads | 0.4-2.0mm |
| Range of imperial threads | 12-52 TPI |
| Spindle accuracy | 0.01mm |
| Spindle speed | 50-1100/100-2500 r.p.m |
| Power of motor | 550W BRUSHLESS |
| Voltage / Frequency | 220V/60Hz |
| Net weight | 40Kg |
| Gross weight | 45Kg |
| Packing size | 800x370x420mm |
