MILLING VISE
The vise body is made from high-quality cast irons The accuracy of the vise (parallelism and squareness) is 0.025mm/100mm. It is often used on milling machines and drilling machines to process surfaces, slots, holes, etc.
The vise body is made from high-quality cast irons The accuracy of the vise (parallelism and squareness) is 0.025mm/100mm. It is often used on milling machines and drilling machines to process surfaces, slots, holes, etc.
Technical Specifications
| Specification | Details |
|---|---|
| 100 | Jaw Width: 100 mm | Jaw Height: 30 mm | Max. Opening: 60 mm | Gross / Net Weight: 9 / 8 kg |
| 125 | Jaw Width: 125 mm | Jaw Height: 40 mm | Max. Opening: 100 mm | Gross / Net Weight: 18 / 17 kg |
| 160 | Jaw Width: 160 mm | Jaw Height: 51 mm | Max. Opening: 180 mm | Gross / Net Weight: 26 / 25 kg |
| 200 | Jaw Width: 200 mm | Jaw Height: 64 mm | Max. Opening: 220 mm | Gross / Net Weight: 38 / 37 kg |
| 250 | Jaw Width: 250 mm | Jaw Height: 64 mm | Max. Opening: 280 mm | Gross / Net Weight: 54 / 53 kg |
| 320 | Jaw Width: 320 mm | Jaw Height: 81 mm | Max. Opening: 360 mm | Gross / Net Weight: 80 / 78 kg |
