IRON WORKER
/ All Models
Punching and shearing force: approximately 60 ton, 90 ton, and 120 ton with stroke rates from 8 to 22 strokes per minute depending on the model. Maximum punching thickness: up to about 15–20 mm with punching diameter around 28–30 mm, and throat depth approximately 220–350 mm.
Punching and shearing force: approximately 60 ton, 90 ton, and 120 ton with stroke rates from 8 to 22 strokes per minute depending on the model. Maximum punching thickness: up to about 15–20 mm with punching diameter around 28–30 mm, and throat depth approximately 220–350 mm.
Technical Specifications
| Specification | Details |
|---|---|
| Model | Q35Y-16 Q35Y-20 Q35Y-25 |
| P unching pressure | 60 TON 90 TON 120 TON |
| Max. Cutting thickness | 16 mm 20 mm 25 mm |
| Plate strength | 450 N/mm 450 N/mm 450 N/mm |
| Cutting angle | 7. 8. 8. |
| Shearing size of the stroke | 16×250 8×400 mm 20×330 10×480 mm 25×330 16×600 mm |
| Slipper stroke | 80 mm 80 mm 80 mm |
| Travel times | 8 mm 8 mm 6 mm |
| Throat depth | 300 mm 355 mm 400 mm |
| Punching thickness | 16 mm 20 mm 25 mm |
| Max. Punching diameter | 25 mm 30 mm 35 mm |
| Main motor power | 4 Kw 5.5 Kw 7.5 Kw |
| Dimensions (LxWxH) | 1640x730x1770 mm1860x800x1990 mm25350x960x2090 mm |
| Weight | 1600 kg 2000 kg 4800 kg |
