Name: Electrical Metal Sheet Shearing Machine 4mm | ALTABSH
SKU: SALLA-1926571891

ELECTRICAL METAL SHEET SHEARING MACHINE

/ 2/4mm

The Electrical Metal Sheet Shearing Machines offer a wide range of high-performance cutting solutions for diverse metal fabrication needs. Featuring a variety of models with different cutting capacities—including thicknesses from 2 mm to 4 mm and cutting lengths from 800 mm to 3200 mm—these machines provide the flexibility and precision required for professional workshops. Each model is engineered for reliability, with a standardized 400 mm backgauge and optimized cutting angles to ensure clean, consistent cuts across all sheet metal sizes and applications.

Export Catalogue

SKU: SALLA-1926571891 Category: Metal Sheet Shearing Machines

Technical Specifications

Specification	Details
Q11-2X800	cutting thickness: 2 mm \| cutting length: 800 mm \| cutting angle: 1°20′ \| backgauge: 400 mm \| Power: 2.2 \| Dimension(mm): 11006401120 \| Weight: 400
Q11-2X1300	cutting thickness: 2 mm \| cutting length: 1300 mm \| cutting angle: 1°20′ \| backgauge: 400 mm \| Power: 2.2 \| Dimension(mm): 16006401120 \| Weight: 430
Q11-2X2000	cutting thickness: 2 mm \| cutting length: 2000 mm \| cutting angle: 1°20′ \| backgauge: 400 mm \| Power: 3 \| Dimension(mm): 2600x920x1220 \| Weight: 900
Q11-2X2500	cutting thickness: 2 mm \| cutting length: 2500 mm \| cutting angle: 1°20′ \| backgauge: 400 mm \| Power: 3 \| Dimension(mm): 3100×920×1220 \| Weight: 1100
Q11-2×3200	cutting thickness: 2 mm \| cutting length: 3200 mm \| cutting angle: 1°20′ \| backgauge: 400 mm \| Power: 4 \| Dimension(mm): 3800x920x1220 \| Weight: 1400
Q11-3X1600	cutting thickness: 3 mm \| cutting length: 1600 mm \| cutting angle: 1°20′ \| backgauge: 400 mm \| Power: 3 \| Dimension(mm): 2200x920x1220 \| Weight: 850
Q11-3×2000	cutting thickness: 3 mm \| cutting length: 2000 mm \| cutting angle: 1°20′ \| backgauge: 400 mm \| Power: 4 \| Dimension(mm): 2600x920x1220 \| Weight: 1000
Q11-3X2500	cutting thickness: 3 mm \| cutting length: 2500 mm \| cutting angle: 1°20′ \| backgauge: 400 mm \| Power: 4 \| Dimension(mm): 3100×920×1220 \| Weight: 1200
Q11-4X1600	cutting thickness: 4 mm \| cutting length: 1600 mm \| cutting angle: 1°20′ \| backgauge: 400 mm \| Power: 4 \| Dimension(mm): 2200x920x1220 \| Weight: 950
