ELECTRICAL HOSE CUTTING AND SKIVING MACHINE DZW-51QG-4 1/4-2 INCHES 380V/3KW 3-PHASE 60HZ
/ DZW-51QG-4
DZW‐51QG‐4 is a hose cutting and skiving machine designed for fast preparation of hoses from 1/4″ to 2″. It uses a 3–4 kW high‐speed motor with an HSS 300 mm blade and a large 350 W extraction fan to deliver clean cuts and quick smoke removal. Adjustable skiving molds and an optional internal skiving unit allow precise removal of hose cover, while the low‐noise motor and protective cover improve safety and comfort in the workshop.
DZW‐51QG‐4 is a hose cutting and skiving machine designed for fast preparation of hoses from 1/4″ to 2″. It uses a 3–4 kW high‐speed motor with an HSS 300 mm blade and a large 350 W extraction fan to deliver clean cuts and quick smoke removal. Adjustable skiving molds and an optional internal skiving unit allow precise removal of hose cover, while the low‐noise motor and protective cover improve safety and comfort in the workshop.
Technical Specifications
| Specification | Details |
|---|---|
| Model | DZW-51QG-4 |
| Voltage / phases 380 | Hz, 3‐phase / 220 V~60 Hz, 3‐phase |
| Cutting motor power | 3 kW / 4 kW, 2850 rpm |
| Working range | 1/4″–2″ hoses |
| Cutting blade | HSS 300 × 2.8 × 32 mm |
| Skiving mold sizes | 10, 13, 16, 19, 25, 32, 38, 51 mm |
| Fan power | 350 W large‐displacement fan |
| Weight / dimensions (L×W×H) | 113 kg; 780 × 560 × 1100 mm |
