DRILL PRESS SP5216C-II 16MM 550W SINGLE PHASE
SUMORE / SP5216C-II
SP5216C-II bench drill press belongs to one of our most economical drill presses
SP5216C-II bench drill press belongs to one of our most economical drill presses
Technical Specifications
| Specification | Details |
|---|---|
| Model | SP5216C-II |
| Drilling capacity | Ø16mm(5/8") |
| Motor power | 375/450/550W |
| Chuck capacity | 3-16mm |
| Spindle stroke | 85mm |
| Class of speed | 16 |
| Speed 60Hz | 180~2770/220~3320 R.P.M |
| Spindle taper | MT2 |
| Auto-feeding step of worktable | 180mm |
| Max distance from spindle end to surface of table | 685mm |
| Max distance from spindle end to surface of base | 1175mm |
| Swing | 360mm |
| Table size | 290x290mm |
| Base size | 460X270mm |
| Column diameter | Ø72mm |
| Height Net | 1600mm |
| weight / Gross weight | 66/70kg |
